NC production
In NC production, machining centers with robots take over the production of complex components. These highly automated plants work with extreme precision and ensure consistent quality, even with large quantities. The combination of state-of-the-art technology and continuous monitoring makes NC production the heart of our production.
Information
3 GROB G350 machining centers with loading robot
Details
- Production of components for film stretching lines and weaving machines
- 5-axis simultaneous machining
- Automatic workpiece measurement with measuring probe
- Tool spindle with up to 16,000 rpm
- 3-shift operation and weekend processing without personnel
- One employee operates 3 machines per shift.
Manufacturing examples
- Gripper heads for weaving machines
- Flaps, clamping bodies and clutch bodies for film stretching systems
3 Heckert HEC 800 machining centers with Fastems pallet system (4-axis)
Details
- Production of large parts for film stretching lines and weaving machines
- Weight: 30 tons
- 320 tool places
- 32 pallet spaces for workpieces on 2 floors
- Maximum workpiece weight: 2.5 tons
- Axis speed: 60 m/min
- Position accuracy of the machine axes: 0.005 mm
Manufacturing examples
- Components for the extrusion of film stretching lines
- Gearbox housing for weaving machines
2 Heller H5000 machining centers with EROWA pallet system (4-axis)
Details
- Production of small and medium-sized workpieces
- Weight: 24 tons
- 270 tool places
- 30 pallet spaces for workpieces on 3 levels
- Maximum workpiece weight: 1 ton
- Axis speed: 80 m/min
- Position accuracy of the machine axes: 0.005 mm
Manufacturing examples
- Pre-machining of all eccentric parts for weaving machine gears
- Reed roller lever for weaving machines
